Tillotson HW Throttle Shaft Finish
Posted by on
To Whom It May Concern,
Tillotson would like to confirm that the surface finish of some HW throttle shafts may vary slightly from the typical production finish, resulting in a duller appearance.
This variation in appearance can occur during the plating process where there is reduced or inconsistent electrical contact with the individual parts. This affects the visual appearance of the finish only.
We confirm that all affected throttle shafts remain within the specified dimensional and measurement tolerances and the difference in finish is cosmetic and does not affect the suitability or performance of the parts.
Best regards,
Andrew Fallon
Product Engineer
Tillotson Ltd
INFO-TECH 1/26 - July 28, 2026 ( Carburetor Pump Cover)
Subject: Carburetor Pump Cover We kindly ask you to acknowledge the attached bulletin and disclose to whomever concerned as integral part of the 2026 technical forms. The two covers listed on the bulletin, refer to the entire range of the Tillotson “HW” series carburetors, supplied OEM with IAME engines. The content of the bulletin will be updated on [...]
Max Bore Size Update
In recent days we have discovered an issue with the max bore size for the Mini Swift and KA100 engines. In both cases, when using the largest size piston available, if the clearance is excessive (a well-worn engine), there is a chance the stated maximum bore size could be exceeded. Until further notice (the 2024 fiche [...]
INFO-TECH 4/23 - June 21, 2023
Subject: Pistons range 41.xx - type IT1 Following the demand increase of the pistons range 41.xx type IT1 (M1 - Gazelle - Norswift - Mini Pro-M - X30 Water Swift) and in order to prevent lack of supply, we have opened a second production line. The pistons from the second line show slightly different markings, due to manufacturer’s needs [...]
INFO-TECH 02/23 – February 14, 2023
Subject: HT coil / pull start engines range Kindly acknowledge that starting from the next supplies, the HT coils provided with the pull start engines (M1/Gazelle/Norswift) will be provided with a security cap installed on the HT cable exit as shown in the pictures below: No performance increase is involved with the modification. Both with or without cap versions are regularly [...]
INFO-TECH 01/23 – February 3, 2023
Subject: Inlet Silencer Reedjet KA100 Kindly acknowledge the modification to the inlet silencer body, supplied as p.n. IAG-90000 with the Reedjet KA100, as shown in the pictures below:The manifold hole on the new version is slightly moved on the left side to allow a better installation of the inlet silencer on the chassis. No performance increase is involved with [...]
INFO-TECH 7/22 - Sept 28, 2022
Subject: Oil Seal TCWJ 20x35x7 - P.N. F-10425A Following supply issues with IAME’s preferred supplier for the oil seal TCWJ 20x35x7 p.n. F-10425A, we have been forced to supply from a second supplier to continue with the production of the engines and the supply of spare parts. The two components are perfectly interchangeable, quality, durability and performance are the equivalent. The [...]
Technical Bulletin: Preventing X30 Coil Failure on Startup
Attention IAME Dealers: There have been some reports of X30 coil failures on engine startup upon using the push button start. Below outlines what causes this failure and how to prevent it. When the start button is pushed the big current (80A approx.) feeding the starter motor passes from the battery to the button, then to [...]
Swift Airbox Tubes
Recently we have discovered that there have been a very small number of airbox tubes for the Mini Swift that were produced outside the specifications defined on the factory fiche document. The overall length is too short. Some of these have made their way into the U.S. market and have been discovered in several areas (race [...]
Notice: X30 Gearbox Venting
The vent fitting onto the X30 crankcase is provided because the gears compartment (like all the gears compartments) need to be vented. The air contained into the gears compartment is heated by the aluminum walls, by the oil and by the gears themselves, as all these parts are heated up during engine operation. As a result, [...]
